Hydraulic Hose DIN EN 856 4SP

Hydraulic Hose DIN EN 856 4SP is designed for very high-pressure applications using petroleum-based hydraulic fluids. En856 4sp hydraulic hoses.

The Hydraulic Hose DIN EN 856 4SP is a specific type of hydraulic hose that conforms to the DIN EN 856 4SP standard. This standard outlines the requirements for hydraulic hoses used in high-pressure applications. This particular hose is designed with four layers of high tensile steel wire reinforcement, providing it with the strength and durability needed to withstand high pressures up to 6000 psi. The synthetic rubber inner tube is resistant to hydraulic fluids, ensuring that the hose maintains its integrity and does not degrade when in contact with these substances.

Overall, the DIN EN 856 4SP hydraulic hose is a reliable and efficient option for applications that require high pressure and reliable hydraulic power delivery. Its construction and design are carefully engineered to meet the stringent standards set forth by DIN and EN, providing users with confidence in the hose’s performance and longevity.

Tube: Synthetic rubber, resistant against hydraulic fluids.
Reinforcement: Four spiral layers of high tensile steel wire.
Cover: Abrasion and ozone resistant synthetic rubber.
Application: Very high-pressure applications used for petroleum-based hydraulic fluids.
Temp. Range. : -40°C To +125°C (-40°F To +230°F)

Specification of Hydraulic Hose DIN EN 856 4SP

This high-quality hydraulic hose meets the stringent requirements of the DIN EN 856 4SP standard, ensuring reliable performance and long service life in demanding applications. Its robust construction and high-pressure rating make it ideal for use in medium-pressure hydraulic lines ranging from 165 to 450 bar.

Furthermore, the hydraulic hose is compatible with a wide range of hydraulic fluids, making it versatile and suitable for various machinery systems. Its flexibility and durability allow for ease of installation and maintenance, while its high-tensile steel wire spirals provide excellent resistance to wear and abrasion.

In conclusion, the Hydraulic Hose DIN EN 856 4SP is a top-quality solution for hydraulic systems requiring medium-pressure transmission. Its reliable performance, compatibility with various fluids, and durability make it a preferred choice for industries that demand high-performance hydraulic

Part No.	SIZE		SAE	I.D		W.D		O.D		W. P		P.P		B.P		min B.R		W.T
#	mm	inch	Dash	Min	Max	Min	Max	Min	Max	Mpa	Psi	Mpa	Psi	Mpa	Psi	inch	mm	Kg/m
SH4SP06	6.3	1/4″	-4	6.2	7	14.1	15.3	17.1	18.7	45	6525	90	13050	180	26100	5.91	150	0.64
SH4SP10	10	3/8″	-6	9.3	10.1	16.9	18.1	20.6	22.2	44.5	6450	89	12905	178	25810	7.09	180	0.75
SH4SP13	12.5	1/2″	-8	12.3	13.5	19.4	21	23.8	25.4	41.5	6020	83	12035	166	24070	9.06	230	0.89
SH4SP16	16	5/8″	-10	15.5	16.7	23	24.6	27.4	29	35	5075	70	10150	140	20300	9.84	250	1.10
SH4SP19	19	3/4″	-12	18.6	19.8	27.4	29	31.4	33	35	5075	70	10150	140	20300	11.81	300	1.50
SH4SP25	25	1″	-16	25	26.4	34.5	36.1	38.5	40.9	28	4060	56	8120	112	16240	13.39	340	2.00
SH4SP32	31.5	1-1/4″	-20	31.4	33	45	47	49.2	52.4	21	3045	42	6090	84	12180	18.11	460	3.00
SH4SP38	38	1-1/2″	-24	37.7	39.3	51.4	53.4	55.6	58.8	18.5	2680	37	5365	74	10730	22.05	560	3.40
SH4SP51	51	2″	-32	50.4	52	64.3	66.3	68.2	71.4	16.5	2390	33	4785	66	9570	25.98	660	4.35
